Bosch CCSD-CURD Conference Control Unit in Bangladesh

The Bosch CCSD-CURD is the advanced control unit for the Bosch CCS-1000D digital conference system which includes MP3 recording facility and digital acoustic feedback suppression.

  • Plug-and-play functionality for quick and easy connection of up to 80 Discussion Devices
  • Intuitive web browser control for advanced configuration and control
  • Built‑in MP3 recorder with internal memory and USB recording
  • Built‑in Digital Acoustic Feedback
  • Built‑in Digital Acoustic Feedback Suppression (DAFS) for ensuring superior speech intelligibility

With this advanced model, up to 8 hours of audio can be recorded to the internal memory, or up to 128GB (>4000 hours) onto an external USB device. The sophisticated ‘digital acoustic feedback suppression’ balances sound pressure levels and system gain to enable higher volumes without howling effects.

Messenger | WhatsApp

SKU: Bosch CCSD-CURD Category: Tags: , , , , , ,
Call Us:

01785-777722, 01711-461346

Office Locations: Uttara | Malibagh

Description

Bosch CCSD-CURD:

Mains voltage100 to 240 VAC ± 10%
Current consumptionMaximum 0.6 A (100 VAC) to 0.2 A (240 VAC)
DC supply to Discussion Devices24 V ± 1 V (current limited)
Number of Discussion Devices per Control UnitMax. 40 devices per trunk connector
Discussion Device loudspeakers volume control15 steps of 1.5 dB (starting from -10.5 dB)
Limit threshold level to unit12 dB above the nominal level
Gain reduction due to the number of open microphones (NOM)1/SQRT (NOM)
Sample rate44.1 kHz
Nominal input (85 dB SPL)< 0.5%
Max. input (110 dB SPL)< 0.5%
XLR nominal microphone input-56 dBV
XLR maximum microphone input-26 dBV
RCA nominal input-24 dBV (+/- 6 dB)
RCA maximum input+6 dBV
S/N> 94 dBA
Frequency response30 Hz to 20 kHz
RCA nominal output-24 dBV (+6/- 24 dB)
RCA maximum output+6 dBV
S/N> 102 dBA
Frequency response30 Hz to 20 kHz
Recording/ Playback (bit rate)64, 96, 128, 256 Kbit/sec
Recording/ Playback (sample frequency)44.1 kHz
Nominal output72 dB SPL
Frequency response200 Hz to 12.5 kHz
Gain range mute-10.5 to +12
SanDisk USB memory stickFormatted with FAT32 file system.Maximum size: 128 GB.
Bite rateInternal memory hours , USB memory stick hours
16 GB32 GB , 64 GB , 128 GB
648 hrs , 500 , 1000 , 2000 , 4000
965 hrs , 350 , 700 , 1400 , 2800
1284 hrs , 250 , 500 , 1000 , 2000
256 *2 hrs , 125 , 250 , 500 , 1000
Dimensions including feet (H x W x D)45 x 440 x 200 mm(1.8 x 17.3 x 7.9 in)19” wide, 1 RU high
Height of feet5.5 mm (0.2 in)
MountingTabletop19-inch rack
Weight (CCSD-CU)Approx. 3.2 kg (7.1 lb)
Weight (CCSD-CURD)Approx. 3.4 kg (7.5 lb)
Material (top)Painted metal
Material (base)Painted metal
Color (top)Traffic black (RAL 9017) matt-gloss
Color (base)Traffic black (RAL 9017) matt-gloss
RimPearl light grey (RAL 9022) matt-gloss
Operating temperature5 ºC to +45 ºC (+41 ºF to +113 ºF)
Storage temperature-40 ºC to +70 ºC (-40 ºF to +158 ºF)
Relative humidity5% to 98% non-condensing
