Anviz C5 Fingerprint & RFID Access Control

Anviz C5 Bangladesh

C5 is a fingerprint & RFID access control system. It integrates color LCD, keypad, optical fingerprint sensor, card reader and access control components. Graphic user interface allows C5 to display all languages in the world. The device has a fashionable and elegant appearance combined with reliable quality. Optional Mifare card reader is specially designed for the existing card users and higher levels of security. Users can have great convenience to manage complicated custom-defined job codes or time attendance statuses. It supports time zone and group access control for high security level.

• Feature

  > 3″ widescreen High Definition TFT display
  > User friendly graphic interface
  > New generation fully sealed, waterproof and dustproof AFOSfingerprint sensor
  > BioNANO V11 core fingerprint algorithm of high speed and stability
  > Support multiple display and software language, Suitable for local market.
  > USB Plug & Play connection
  > RS232/RS485, Mini USB Slave and TCP/IP for network connection
  > Standard RFID, optional Mifare reader
  > Clear voice prompts along with all operations
  > 12-digit user ID and user name display
  > 16 different customizable time and attendance status
  > Auto time and attendance status switch
  > 6-digit work code to calculate different job cost
  > Public and private short message display
  > Auto daylight saving
  > Direct lock control to open door, door open sensor.
  > Support Wiegand 26 Input and Output, Support Anviz Wiegand Output
  > Optional SC011/SC844 or any other standard access controller for separate type secure access control system
  > Time zone and group access control, realtime data transfer monitor
  > Standard 3000 fingerprints and 50000 records
  > Wall mounted, combine 2-in-1 function for access control and time attendance

• Parameter

  Algorithm	BioNANO V11
  Sensor	AFOS, NOT AFOS
  Scan Area	22mm*18mm
  LCD	3″ Widescreen High Definition TFT Display
  Identification Time	<0.5 Sec
  FRR	0.001%
  FAR	0.00001%
  Capacity	Max 3,000 Capacities
  Template	Max 3,000 Templates
  Logs	50,000 Logs
  Card Reader Module	125KHZ EM RFID, Optional 13.56MHZ Mifare
  Identification Mode	FP, Card, ID+FP, ID+PW, PW+Card, FP+Card
  Voice Prompt	Support Multiple Languages Display and Voice Prompt
  Self-defined Status	16
  Work Code	6-digit Work Code
  Short Message	Supports Up to 50 Public or Private Message Simultaneously Displayed
  Scheduled Bell	Yes
  Daylight Saving	Manual Mode, Automatic Mode
  Relay	1 Relay
  Access Groups & Time Schedules	16 Groups, 32 Time Zones
  Door Sensor	Yes
  Humidity	20% ~ 80% RH
  Web Server	Yes
  Communication Interface	TCP/IP, USB Host, USB, RS232, RS485
  Wiegand	Support Wiegand 26 Input and Output, Support Anviz Wiegand Output
  Operating Voltage	DC12V, 1A
  Size	168mm (W) * 130mm (H) * 37mm (D)
  Temperature	-20℃ ~ 65℃

• Application

  •

Download

•
