Description
Ahuja LXA-1400 675+675 WATTS Dual Channel PA Power Amplifier
| Continuous Rated Power | . |
| Stereo/Mono | 8Ω : 2 × 250W, 4Ω : 2 × 475W 2Ω : 2 × 675W |
| Bridged Output | 8Ω : 950W, 4Ω : 1350W |
| THD + N | < 1.0% |
| Frequency Response (-1dB) | 20-20,000Hz |
| Power Bandwidth (0.5% THD) | 20-20,000Hz |
| Input Sensitivity | 0dBm (775mV)/1.23V (selectable) |
| Input Impedance | 10k Unbalanced, 20k Balanced |
| S / N Ratio | > 95dB |
| Channel Separation | > 65dB at 1kHz |
| Damping Factor | 400 : 1 (8Ω) |
| Slew Rate | 35V/µs |
| Protections | Temperature, DC, RFI, Short Circuit, Overload, Built-in Limiter, AC: Fuse 10Amp. (T 10A L); ± DC: Fuse 2 x 10Amp. (T 10A L) for each zone, ± DC: Fuse 2 x 2Amp. (for fan supply) |
| Input Connectors | 2 × XLR, Stereo Phone Jack 6.3mm |
| Output Connectors | Speakon 4-Way, Heavy duty Binding Post for each channel |
| Cooling | Variable Speed DC Fan with Temperature Sensing |
| Front Panel Controls | 2 × 21 Step Level Attenuators |
| Indicators | Power ON, Signal, Clip, Temperatures, Protect (Ch. A & B) |
| Power Consumption (Rated) | 1800VA @ 240V / 50Hz |
| Dimensions | W482 × H113 × D460 mm |
| Weight | 14.7kg |
