- 1/2.9″ SONY Sensor
- Board Lens 3.6mm
- With IR-CUT, Low Illumination
- IR Effective Distance: 20M
| Technical Specification | |
| Model | SG-LAS24AHDS |
| Image Sensor | 1/2.9″ SONY Sensor |
| DSP | FH8550D |
| Image Resolution | 1080P |
| Effective Pixels | 1920*1080 |
| TV System | PAL/NTSC |
| Electronic Shutter | 1/25s~1/50,000s, 1/30s~1/60,000s |
| S/N Ratio | ≥50dB |
| Scanning System | Progressive Scan |
| Lens / Pixels | 3.6mm / 3M Pixels |
| Infrared LED | 14MIL*18PCS |
| Infrared Distance | 20M |
| IR Status / IR Power On | Under 10 Lux by CDS / CDS Auto Control |
| Day/Night | YES |
| White Balance | AUTO / MANUAL |
| Gain Control | AUTO |
| Noise Reduction | 3DNR |
| WDR / OSD / UTC | YES |
| Illumination | Low Illumination |
| Housing | plastic |
| Dual Voltage | NO |
| IR Cut Filter | YES |
| Operation Temperature | -10℃ ~ +50℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10%, 500mA |
| Dimension | 94(W) x69(H) |
| Weight | 190g |
