Description
BNC With Connector (MX)
A CCTV camera is a device with an integrated video camera that can be placed in public or private areas to monitor activity. A BNC connector, also known as a Bayonet Neill-Concelman connector, is an RF connector that is typically used in coaxial cable systems. The BNC connector mates with the coaxial cable by twisting on with bayonet style.
A CCTV Camera BNC With Connector, or a BNC Jack for Coaxial Cable, is a device that connects a video transmission to a coaxial cable. A CCTV Camera BNC With Connector is also used when there’s not enough room to plug in the camera directly into the coaxial cable. It also provides protection from electrical interference and corrosion.
Uses of CCTV BNC Connector:
MX BNC connectors used for CCTV cameras and DVR systems can be utilized to join a range of coaxial cables. The connector is equipped with superior architecture with snap-lock. BNC connectors are used with miniature-to-subminiature coaxial cable in radio, television, and other radio-frequency electronic equipment, test instruments, and video signals.
Specifications of MX BNC with Connector:
- Impedance: 50Ω, 75Ω
- Frequency range: 0 ~ 4 GHz
- Resistance: Inner conductor ≤ 2.0mΩ
- External resistance: ≤ 0.2mΩ
- Insulation Resistance: ≥ 5000MΩ
- Withstand Voltage: 1500V rms
- Durability: over 1000 times
- Center Pin: Brass
- Frequency response: DC to 8 MHz
- Attenuation: 0.5dB type
- Material: Plastic and Copper
- Working temperature: -20°C ~ 75°C
- Storage temperature: -30°C ~ 85°C
- Humidity: 0% ~ 95%RH
TRIMATRIK MULTIMEDIA is the Solutions Provider, Supplier, Dealer, Distributor, Importer & Wholesaler of CCTV BNC with Connector in Dhaka, Chittagong, Sylhet, Khulna, & all over in Bangladesh. To buy CCTV BNC (Bayonet Neill–Concelman) with Connector, you can contact us.
